SIZES: 1/2″ through 36″ (15 through 900 mm)
RATING CLASS: 150, 300 and 600
BODY MATERIALS: Carbon Steel, Chrome-Moly, Stainless Steel, Duplex, Hastelloy, Monel, Alloy 20, Bronze, CZ 100, Titanium, Most other Alloys
END CONNECTIONS: Integral or separable flanges: ANSI 150-600, UNI-DIN 10-100, SW or BW, NPT, Grayloc®
TRIM MATERIALS: Equal percentage, Linear, Quick Open, Quick change seat, Stainless Steel 316 or 420, Duplex, Most other Alloys
ACTUATOR: Double Acting cylinder with spring for failsafe action, Electric, Hydraulic options
FEATURES: Versatile configurations: single seat, cage, angle, 3-ways, steam-jacketed, cryogenic, micro flow, bellows seal, low noise and anticavitation, reduced trims. Double top-stem guiding designed out of stream and large stem diameter ensures shutoff and no galling or sticking, Simple to service and maintain
